Altos BrainSphere™ Server T110 F6

Altos BrainSphere™ T110 F6 Server

Altos BrainSphere™ T110 F6 delivers true server-class features and expandability along with best price-performance technology to assure the success of your business. This single-socket tower server features an 80 PLUS® efficient power supply that runs smoothly and quietly for maximized productivity.

Features

Powerful performance

With Intel Xeon® E-2300 Processors, the Altos T110 F6 represents an architectural turning point for professional high-end compute needs. The all-new architecture optimizes CPU performance, allowing entry servers, secure cloud services, and edge devices/appliances to work at their best with up to 8 cores.

Flexible expansions

Altos T110 F6 combines double PCIe Gen4 expansion slots, PCIe Gen3 M.2 NVMe SSD slots, and support for up to 4 DIMM DDR4 ECC UDIMMs and 4 3.5” SATA drive bays with RAID 0,1,5 or 10 to provide users with enhanced flexibility.

Management capabilities

Altos T110 F6 is equipped with a built-in AST2500 controller, which provides robust remote management and monitoring capabilities for the workstation. With the AST2500 controller, IT administrators gain comprehensive control over the system and the ability to troubleshoot issues remotely, regardless of their location. This feature enhances the overall reliability of the system by enabling efficient management and reducing downtime.

Specifications

Altos BrainSphere™ T110 F6 Server
Altos BrainSphere™ T110 F6 Server

Altos BrainSphere™ T110 F6 Server

  • Processors:Single Intel® Xeon® E-2300 Processor (LGA1200), up to 8 Core / 95W TDP
  • Power Supply:500W Multiple output 24 pins, 80PLUS® Brown PSU
    450W Multiple output 24 pins, 80PLUS® Gold PSU (optional)
Specifications
Processors Single Intel® Xeon® E-2300 Processor (LGA1200), up to 8 Core / 95W TDP
Number of Processor 1
Memory 4 DIMM slots (Dual channel)
Up to 128GB ECC DDR4 3200 MHz UDIMM
I/O Expansion 1 PCI-E 4.0 x16 slot
1 PCI-E 4.0 x8 slot (x4 Lanes)
1 M.2 2280 PCI-E 3.0 slot
Management Network Interface (Controller) Dual RJ45 1 Gb/s Ethernet LAN Port (Intel® i210AT, share IPMI port)
Single RJ45 10/100/1000 management LAN
Storage Media bay: 2x 5.25" slot:For ODD
Storage bay: 4 x 3.5"/2.5" slots:For hard disks
Power Supply 500W Multiple output 24 pins, 80PLUS® Brown PSU
450W Multiple output 24 pins, 80PLUS® Gold PSU (optional)
OS Support Microsoft® Windows Server® 2022
Red Hat Linux 6.9/7.3/8.6/9.0
SUSE Linux Enterprise Server 11.2/12.2/15
Ubuntu 16.04.6/18.04.2/20.04.4/22.04
Dimension 386 (D) x 175 (W) x 360 (H) mm (15.2 x 6.89 x 14.17 inches)
  • Integrated SATA RAID supports RAID 0, 1, 5, 10 on Windows® OS only.
  • Extended warranty services may vary by country. Please contact Altos for more information
